Barrier Gate

TTS260

  • Electro-mechanical tripod turnstile
  • 2Built in controller for programmable lock delay. Bigger
  • housing.  Anti-tailgating.

TTS230

  • Electro-mechanical tripod turnstile
  • Built in controller for programmable lock delay.
  • Slanted plastic plate allow easy integration with any
  • access control reader.  Anti-tailgating.

 TTS210

  • Mechanical tripod turnstile
  • Simple mechanism without controller. Tripod arm islock and un
  • lock using solenoid.  Optimized smaller
  • size to fit into extremely tight space

TTS330

  • MAG standard size tripod turnstile
  • Built in controller for programmable lock delay.
  • Slanted plastic plate allow easy integration with any
  • access control reader.  Anti-tailgating and other
  • innovative features with built-in controller.

TTS310

  • MAG mini size tripod turnstile
  • Simple mechanism without controller. Tripod arm is
  • lock and unlock using solenoid.  Optimized smaller
  • size to fit into extremely tight space.

UM6160C

  • LED Digital Counter
  • 8 Digit LED digital counter display the numbers of
  • visitors enter the premise. Require 12VDC power
  • supply.

DHC3J

  • LCD Digital Counter
  • 8 Digit LCD digital counter display the numbers of
  • visitors enter the premise. Running on battery to last
  • maximum 3 years.

SL12V

  • Solenoid lock
  • Optional accessories for TTS210. Allow electronic
  • access control system to lock or unlock  the arm
  • rotation. Operating in 12V.
  • Requires one solenoid for each direction.  Required
  • Tito install at both side if turnstile is used as bi-
  • directional.

BR5AEF

  • MAG Fence arm
  • Especially useful for longer arm where there is a
  • big opening space underneath the arm.  Fence
  • arm effectively block pedestrian trying to pass
  • through from underneath.

BR5A90

  • MAG Folding arm 90
  • Arm will be folded into 2 separate portion in 90 as
  • the arm lift up.  This allowed installation for site
  • that have low height such as basement or multi-
  • level indoor parking.

BR500 series

  • MAG IntelliBarrier gate
  • AC motor. Not limit switch design minimize
  • mechanical wear and allowed superb operating
  • life time.  Weather resistant with plastic coating.
  • Arm length can be customized according to site.
  • BR510 - 1 sec
  • BR530 - 3 sec
  • BR560 - 6 sec

EQ-501

  • Sunx infrared transceiver

  • Comes with transmitter and receiver built into a

  • Relay contact output.  20 msec response time.

  • Detecting presence of pedestrian, animal, other

  • vehicle or any other object that might be blocking

  • the pathway   Avoid arm to accidentally fall onto the

  • pedestrian or vehicle - additional safety measure.





BRD05-PD132

  • Single channel loop detector

  • Detect presence of vehicle.  Is used to confirm that

  • the vehicle have completely passed through before

  • the aluminum arm fall down to closing position.

  • Power input is AC230.
